The new Symphony series components are affordable, no compromise component sets suitable for car audio aficionados and Audiophiles alike.
Symphony 5.25″ Mid-Woofer
The Symphony 5.25 Midwoofer has been designed with a Rigid Stamped steel powder coated basket. Utilizing an efficient motor structure with a 12oz High-Grade Ferrite magnet, the Symphony components have enough motor force to keep up with most music at high volume, while still providing great punch in the midbass range.
A lightweight, high Temperature 1.1″ voice coil provides great power handling while keeping solid efficiency.
The Cone & dustcap is made of our Proprietary Fiberglass weave, allowing for a rigid cone for minimal break-up at high volumes, and also features a compound rubber surround for excellent mechanical excursion compliance.
Symphony Crossover
Crossing over a great set of speakers passively is never an easy task, so crossover design is very important.
The crossovers allow flexibility in any install with a Small footprint, and selective tweeter dB output circuit.
High quality, low tolerance capacitors are used in the 12dB high and 6db low-pass circuits, allowing for minimal loss at the crossover itself, along with perpendicular mounted inductors to eliminate cross-talk in between the midwoofer and tweeter.
Symphony Tweeter
The Symphony series deserved a smooth, high output tweeter.
This includes a natural high quality 22mm silk dome, along with a High grade Neodymium magnet structure.
The 20mm copper voice coil is designed for good power handling and efficiency.
SC-525 Specifications | |
Power rating RMS |
100 Watts |
Sensitivity |
89 dB 1W/1m |
Frequency response |
70Hz – 21KHz |
Impedance |
4 Ohm |
Crossover Slope |
2 x 12 dB L/H |
Crossover frequency |
3800 Khz |
Symphony 5.25″ Woofer | |
Mounting depth |
2 1/4″ |
Overall Diameter |
5 1/8″ (Mounting tabs are 6″ end to end) |
Hole Cutout |
4 1/2″ |
Symphony 22mm Tweeter | |
Mounting depth |
5/8″ |
Overall Diameter |
2″ |
Hole Cutout |
1 13/16″ |
Crossover size- 2 5/8″ x 4 3/4″
